HarvesterTerrainMask

Introduction

The HarvesterTerrainMask is a C# script in a Unity game development project that represents a component of the Harvester class. This script generates a TerrainMask which is used to mask out areas of a terrain in a game where the harvester cannot operate.

The HarvesterTerrainMask class creates a Texture2D and a RenderTexture that are used to create the TerrainMask. It also uses a shader to render the mask on the terrain.

The HarvesterTerrainMask provides methods to create and update the TerrainMask based on the size of the terrain, the position of the camera, and the radius of the harvester’s detection range. It also provides methods to apply and remove the TerrainMask on the terrain.

This component is crucial to the Harvester class as it allows the harvester to operate only on areas of the terrain that are harvestable. By masking out non-harvestable areas, it prevents the harvester from accidentally destroying objects that should not be harvested, thus preventing game-breaking bugs and enhancing the user experience.

Overview

HarvesterTerrainMask is a class that removes trees on a terrain that are within a specified box collider.

Interface pages:

None

Constructor pages:

None

Method pages:

Method Name	Return Type	Description
Start()	void	The Start method is called before the first frame update. It initializes the class variables, backs up the original terrain trees, and removes trees that are within the box collider.
removeTree(Terrain thisTerrain, TreeInstance treeInstance)	void	The removeTree method removes the specified tree from the terrain.
GetTerrainFromName(string terrainName)	Terrain	The GetTerrainFromName method returns the terrain instance with the specified name.
OnDisable()	void	The OnDisable method is called when the game object is disabled. It restores the original terrain trees.
OnDestroy()	void	The OnDestroy method is called when the game object is destroyed. It restores the original terrain trees.

Property pages:

Property Name	Type	Description
boxCollider	BoxCollider	The box collider that defines the area to search for trees to remove.
vegetationDetectionDistance	float	The distance from the terrain at which trees are detected.
harvestableObject	HarvestableObject	The harvestable object.
harvestableCollider	HarvestableCollider	The collider for the harvestable object.
Trees_On_Terrain	TreeInstance[]	The array of tree instances on the terrain.
thisObjectsTerrain	Terrain	The terrain that this object is on.
originalTrees	TreeInstance[]	The array of original trees on the terrain.
NewTrees_On_Terrain	List<TreeInstance>	The list of new tree instances on the terrain.

Event pages:

None

Concept/guide pages:

None

Examples:

None
